About this 2004 Suzuki Liana (RH418) Scan Data Set

This 2004 Suzuki Liana (RH418) (1.8L M18A 4cyl 16v DOHC VVT MPFI Petrol) page collates 3 diagnostic files and 12 scan or scope images submitted by qualified automotive technicians across 6 data categories. Every file in the set was captured from a vehicle that was running correctly at the time of recording, giving technicians a known good baseline to compare against when diagnosing a faulty 2004 Liana (RH418) in their own workshop.

Captures in this set span KOEO (Key On Engine Off), engine idle, 2000 RPM raised idle and cranking operating states — the canonical conditions the TaT community records against so that readings can be compared directly between a known good vehicle and a customer's car presenting symptoms.

Typical uses for a data set like this include verifying live-data PID values and freeze-frame snapshots, confirming oscilloscope waveform shape and timing for primary and secondary ignition, checking CAN bus activity on modules that are suspect, and ruling out good-component scan tool readings when chasing an intermittent fault on the same chassis. Every file is attributed to the submitting member and reviewed before it appears on the site.
