About this 2011 Audi A4 (B8) Scan Data Set

This 2011 Audi A4 (B8) (2.0L CDNB 4cyl 16v DOHC VVT Turbo Direct Inj Petrol) page collates 1 diagnostic file and 34 scan or scope images submitted by qualified automotive technicians across 2 data categories. Every file in the set was captured from a vehicle that was running correctly at the time of recording, giving technicians a known good baseline to compare against when diagnosing a faulty 2011 A4 (B8) in their own workshop.

Typical uses for a data set like this include verifying live-data PID values and freeze-frame snapshots, confirming oscilloscope waveform shape and timing for primary and secondary ignition, checking CAN bus activity on modules that are suspect, and ruling out good-component scan tool readings when chasing an intermittent fault on the same chassis. Every file is attributed to the submitting member and reviewed before it appears on the site.
